Alloy Steel Plate

ASTM A387/ SA387 Low Alloy Sheet supplier in India

Alloy steel plates are made from different alloys of steel. These flanges have a composition of nickel, chromium, molybdenum along with a few trace elements. These plates have good resistance to corrosion and high temperatures. Apart from this, the SA387 Alloy Steel Plates have high weldability, durability, good tensile, and yield strength. Alloy steel plates are widely used in the construction industry for building bridges, bars, structural sections, etc. They also have applications in processing plants, petrochemical, and chemical industries. We are the top Alloy Steel Plate Supplier in India, who focus on creating the best products at reasonable rates.

Buy Chrome Molybdenum Cold Rolled Coil at factory Price, View Dimensions of ASTM A387 Alloy Sheet

ASTM A387 Sheet is formed from industrial processes into thin and flat pieces. These sheets can be easily bent and given different shapes. A sheet can be used to fabricate many daily-use items. The 6150 alloy steel Chequered Sheets is punched or stamped to produce a design on one side while the other side is blank. These sheets can have good anti-slid properties. They can also be used as decorating material on roofs or houses. All our products are prepared using the best technology and the best raw material by our renowned staff.

The ASME SA387 Alloy Steel Class 1 Cold Rolled Plates are formed after processing hot-rolled plates. In this cold rolling process, power rollers are used on the sheet to put pressure on them. This results in the formation of a thinner and stronger product. The Chrome Molybdenum Cold Rolled Coil is a highly corrosion-resistant coil. All our products can be customized into different shapes and sizes to suit all your needs. If you have any queries regarding our alloy steel plates or other products, contact us for more information.

Specification List of Alloy Steel Plate

Specification ASTM A387 / ASME SA387
Thickness 0.1mm to 100 mm Thk
Finish Cold rolled sheet (CR), Hot rolled plate (HR), 2B, 2D, BA NO(8), SATIN (Met with Plastic Coated)
Condition Polished on both sides
Export to Thailand, Egypt, Ireland, Brazil, Singapore, Indonesia, Korea, Iran, Spain, Canada, India, Saudi Arabia, Oman, Dubai, Ukraine, USA, Peru, etc
Stock in form of Plate, Sheet, Coils, Shim Sheet, Strip, Flats, Clad Plate, Rolling Sheet, hot rolled, cold rolled, annealed, Flat Sheet, Rolling Plate, tread plate, Foils, Rolls, Blank (Circle), soft annealed, descaled, Plain Sheet, Flat Shim, sheared, Checker Plate
Value Added Service Pickling, Cladding, Heat Treatment, Annealed,Cutting, Bending, Forging, Minor Fabrication, Polish, Rolling Etc.
Width 10-2500mm
Hardness Hard, Half Hard, Soft, Spring Hard, Quarter Hard etc.
Temper Annealed
Dealers & Distributor of JINDAL, TATA, POSCO, JISCO, TISCO, BHUSHAN, SAIL, ESSAR, INDIAN, LISCO, BAOSTEEL IMPORTED material
Test Report
  • EN 10204/3.1B
  • Third Party Inspection Report, etc
  • 100% Radiography Test Report
  • Strict Control from Raw Material to Finished
  • High special strength, high melt point
  • Customer support after-sales service
  • Raw Materials Certificate
  • Excellent corrosive resistance, good thermal resistance
Profiling

To provide a full profiling service we use numerous profiling methods including:

  • Plasma Plate Cutting
  • Oxy-propane Flame Cutting
  • Laser Plate Cutting
Specialized in
  • material under 3/16 " [5.00 mm] in thickness and 24" [600 mm] and over in width
  • cold-rolled material under 3/16" [5.00 mm] in thickness and under 24" [600 mm] in width
  • material 3/16" [5.00 mm] and over in thickness and over 10" [250 mm] in width
  • Free Quote, Inquiry answered within 24 hours
Length & Sizes 1000 mm x 2000 mm, 1000 mm x 2000 mm, 1220 mm x 2440 mm, 1250mm x 2500mm, 1500mm x 3000mm to 6000mm, 2000mm x 4000mm to 6000mm, 1500 mm x 3000 mm, 2000 mm x 2000 mm, 2000 mm x 4000 mm, 2m, 2.44m, 3m, 36" X 120" or 48" X 144", 4' x 8', Cut to size available

Alloy Steel Plate Price Per Kg In India

Price list of Alloy Steel Plate Alloy Steel Sheet Price in INR Low AS Plate Price in USD Alloy Steel Plate Price in UAE Dirham
HOT ROLLED ALLOY STEEL SHEET IN COIL GR.DIN EN10149-2 S 650MC SIZE(MM) INR 215 2.93 USD 10.76 UAE Dirham

ASTM A387 Polished Hot Rolled Coil Dimension Chart

Metric Dimensions

Surface finish Thickness (mm) Width (mm)
2B – Cold rolled, heat treated, pickled, skin passed 0.25–8.0 max. 2032
2D – Cold rolled, heat treated, pickled 0.4–6.35 max. 1524
2E – Cold rolled, heat treated, mechanically descaled 0.4–8.0 max. 2032
2R – Cold rolled, bright annealed 0.25–3.5 max. 1524
2H – Work hardened 0.4–6.35 max. 1524
Polished, brushed 0.5–4.0 max. 1524

Imperial Dimensions

Surface finish Gauge (in) Width (in)
2B – Cold rolled, heat treated, pickled, skin passed 10–24 max. 72*
2D – Cold rolled, heat treated, pickled 12–24 max. 60
BA Mexinox only 18–28 max. 48
Polished (not brushed) 11–24 max. 60
Temper rolled Mexinox only 13–29 max. 48

View Thickness of ASME SA387 Alloy Steel Class 1 Cold Rolled Plates, Check ASTM A387 Polished Hot Rolled Coil Price List

4130 Alloy Steel Sheet Weight chart

Thickness Plate Weight per Unit Area Density
3/16 inches 0.06000 lbs/in²42.184176 kg/m² 0.315 lbs/in³8.72 g/cm³
1/4 inches 0.08 lbs/in²56.245568 kg/m² 0.315 lbs/in³8.72 g/cm³
3/8 inches 0.121 lbs/in²85.0714216 kg/m² 0.315 lbs/in³8.72 g/cm³
1/2 inches 0.161 lbs/in²113.1942056 kg/m² 0.315 lbs/in³8.72 g/cm³
5/8 inches 0.196 lbs/in²137.8016416 kg/m² 0.315 lbs/in³8.72 g/cm³
3/4 inches 0.235 lbs/in²165.221356 kg/m² 0.315 lbs/in³8.72 g/cm³
7/8 inches 0.274 lbs/in²192.6410704 kg/m² 0.315 lbs/in³8.72 g/cm³
1 inches 0.313 lbs/in²220.0607848 kg/m² 0.315 lbs/in³8.72 g/cm³
1 1/4 inches 0.391 lbs/in²274.9002136 kg/m² 0.315 lbs/in³8.72 g/cm³
1 1/2 inches 0.47 lbs/in²330.442712 kg/m² 0.315 lbs/in³8.72 g/cm³
1 3/4 inches 0.549 lbs/in²385.9852104 kg/m² 0.315 lbs/in³8.72 g/cm³
2 inches 0.627 lbs/in²440.8246392 kg/m² 0.315 lbs/in³8.72 g/cm³
2 1/4 inches 0.705 lbs/in²495.664068 kg/m² 0.315 lbs/in³8.72 g/cm³
2 1/2 inches 0.784 lbs/in²551.2065664 kg/m² 0.315 lbs/in³8.72 g/cm³
2 3/4 inches 0.862 lbs/in²606.0459952 kg/m² 0.315 lbs/in³8.72 g/cm³
3 inches 0.941 lbs/in²661.5884936 kg/m² 0.315 lbs/in³8.72 g/cm³

ASME SA387 Alloy Steel Sheet Size chrat

SIZE SIZE
.125" 3.18mm
.134" 3.40mm
.156" 3.96mm
.187" 4.75mm
.250" 6.35mm
.312" 7.92mm
.375" 9.53mm
.500" 12.7mm
.625" 15.9mm
.750" 19.1mm
.875" 22.2mm
1" 25.4mm
1.125" 28.6mm
1.250" 31.8mm
1.500" 38.1mm
1.750" 44.5mm
2" 50.8mm
2.500" 63.5mm
3" 76.2mm

Thickness of Aisi 4140 Alloy Steel Plate

Thickness
in. (mm)
Sheet Width
36 (914.4)
in. (mm
48 (1,219)
in. (mm)
0.017–0.030 (0.43–0.76) 0.0015 (0.038) 0.002 (0.051)
0.031–0.041 (0.79–1.04) 0.002 (0.051) 0.003 (0.076)
0.042–0.059 (1.1–1.5) 0.003 (0.076) 0.004 (0.10)
0.060–0.073 (1.5–1.9) 0.003 (0.076) 0.0045 (0.11)
0.074–0.084 (1.9–2.1) 0.004 (0.10) 0.0055 (0.14)
0.085–0.099 (2.2–2.5) 0.004 (0.10) 0.006 (0.15)
0.100–0.115 (2.5–2.9) 0.005 (0.13) 0.007 (0.18)
0.116–0.131 (2.9–3.3) 0.005 (0.13) 0.0075 (0.19)
0.132–0.146 (3.4–3.7) 0.006 (0.15) 0.009 (0.23)
0.147–0.187 (3.7–4.7) 0.007 (0.18) 0.0105 (0.2
Super strength Chrome Molybdenum Strips manufacturer in India, Buy directly from 6150 alloy steel Chequered Sheets in Mumbai

Various Types of ASTM A387 Sheet

Chemical Structure of 2ASME SA387 AS Shim Stock

Grade C Si Mn P max % S Max % Cr Mo
ASTM A 387 GR.2 0.05-0.21 0.15-0.40 0.55-0.80 0.035 0.035 0.50-0.80 0.45-0.60
ASTM A 387 GR.5 0.15 max 0.50 max 0.30-0.60 0.030 0.030 4.00-6.00 0.45-0.60
ASTM A 387 GR.9 0.15 max 1.00 max 0.30-0.60 0.030 0.030 8.00-10.0 0.85-1.10
ASTM A 387 GR.11 0.05-0.17 0.15-0.40 0.40-0.65 0.035 0.035 0.80-1.15 0.45-0.60
ASTM A 387 GR.12 0.05-0.17 0.15-0.80 0.40-0.65 0.035 0.035 1.00-1.50 0.45-0.65
ASTM A 387 GR.22 0.05-0.15 0.50 max 0.30-0.60 0.035 0.035 2.00-2.50 0.90-1.10
ASTM A 387 GR.91 0.08-0.12 0.20-0.50 0.30-0.60 0.020 0.010 8.00-9.50 0.85-1.05
ASTM A 204 GR. A 0.18 max 0.15-0.40 0.90 max 0.035 0.035 - -
ASTM A 204 GR. B 0.20 max 0.15-0.40 0.90 max 0.035 0.035 - -

Mechanical Behaviour of Low Alloy High Strength Steel Plate

Grade Yield strength MPa Tensile strength MPa Elongation GL=2 in. or 50mm
ASTM A 387 GR.2 310 min 485 - 620 22
ASTM A 387 GR.5 310 min 515 - 690 18
ASTM A 387 GR.9 310 min 515 - 690 18
ASTM A 387 GR.11 310 min 515 - 690 22
ASTM A 387 GR.12 275 min 450 - 585 22
A 387 91 SA 387 91 10CrMoVNb9-1 -
ASTM A 387 GR.22 310 min 515 - 690 18
ASTM A 387 GR.91 415 min 585 - 760 18
ASTM A 204 GR. A 255 min 450 – 585 23
ASTM A 204 GR. B 275 min 485 - 620 21
Looking for cheap & best quality ASME SA387 AS Shim Stock Stockist in india? View Alloy Steel 4340 Plate Weight Chart
